AIKO N Type ABC 650W Solar Panel
- AIKO
- China
- 7days
- high
The AIKO 650W ABC Solar Panel combines advanced N-Type technology, proven R&D, and massive production strength, ensuring reliable supply, global sales success, and versatile applications.
AIKO N-Type ABC 650W Solar Panel
Product Overview
The AIKO N-Type ABC 650W Solar Panel represents a new generation of photovoltaic technology. Powered by All Back Contact (ABC) architecture and N-Type crystalline silicon cells, this module delivers industry-leading efficiency, outstanding durability, and an elegant, busbar-free appearance. Designed for residential rooftops, commercial projects, and utility-scale plants, the 650W ABC panel sets a new benchmark in solar innovation.
Key Features
650W High Power Output
Significantly reduces the number of panels required, lowering system installation and BOS (Balance of System) costs.Up to 24% Module Efficiency
Among the highest in the industry, ensuring maximum power generation per square meter.ABC (All Back Contact) Technology
Eliminates front-side busbars, improving light capture and enhancing aesthetics with a sleek, black-glass finish.N-Type Cell Advantages
No LID (Light Induced Degradation)
Lower temperature coefficient (-0.29%/°C)
Higher bifaciality for improved real-world yield
Premium Aesthetics
Modern, elegant, and busbar-free appearance – ideal for high-end rooftops and architectural integration.Durable & Reliable
Certified to withstand high wind (2400 Pa) and snow loads (5400 Pa). Resistant to salt mist, ammonia, PID, and extreme weather conditions.
Technical Specifications (AIKO ABC 650W)
| Parameter | Specification |
|---|---|
| Model | AIKO N-Type ABC 650W |
| Power Output (Pmax) | 650W |
| Module Efficiency | Up to 24.0% |
| Cell Technology | N-Type Monocrystalline ABC |
| Dimensions | ~2384 × 1303 × 35 mm |
| Weight | ~38 kg |
| Temperature Coefficient (Pmax) | -0.29% / °C |
| Operating Temperature Range | -40°C ~ +85°C |
| Front Glass | 2.0mm Tempered Glass, Anti-reflective |
| Frame | Anodized Aluminum Alloy |
| Junction Box | IP68 Rated, 3 Bypass Diodes |
| Maximum System Voltage | 1500V DC |
| Product Warranty | 15 Years |
| Power Warranty | 30 Years (≤1% degradation in year 1, ≤0.4% annually thereafter) |
Applications
Residential Rooftops – Space-saving with high efficiency and modern aesthetics.
Commercial & Industrial Systems – Reduce electricity costs with reliable and powerful generation.
Utility-Scale Projects – High-power density reduces land and system costs.
Challenging Environments – Certified for coastal, desert, and humid regions.
Why Choose AIKO ABC 650W?
Cutting-edge N-Type ABC technology
High efficiency & long lifespan – ensuring maximum ROI
Sleek design – perfect for premium installations
Trusted global brand – AIKO is recognized as a Bloomberg Tier 1 supplier and one of the world’s most bankable solar companies
Packaging & Delivery
Modules packed in reinforced pallets with protective corners
40HQ container capacity: ~580–600 panels (depending on packaging)
Flexible shipping options available worldwide
